FlowBase G2

Lighting up tunnels for optimum safety

Products

Product Compare
BWP352 LED118/NW 80W 220-240V DM2 G2
911401630307
140
11800
4000
BWP352 LED139/NW 100W 220-240V DM2 G2
911401630507
140
13900
4000
BWP352 LED70/NW 50W 220-240V DM2 G2
911401629907
140
7000
4000
BWP352 LED162/NW 120W 220-240V DM2 G2
911401630707
140
16200
4000
BWP352 LED130/NW 90W 220-240V DM2 G2
911401630407
140
13000
4000
BWP352 LED76/NW 60W 220-240V DM2 G2
911401630007
140
7600
4000
BWP352 LED245/NW 180W 220-240V DM2 G2
911401631007
140
24500
4000
BWP352 LED316/NW 220W 220-240V DTXB G2
911401631407
140
31600
4000

Product family information

Description

A lighting design that ensures safety and good visibility is a key element in the success of any tunnel project. Philips FlowBase G2 combines compact design, reliability, and affordability in one complete package to bring the perfect lighting solution for any tunnel application.

Benefits

  • High lumen efficacy for energy saving

  • Robust quality and reliability

  • Professional optics for tunnel applications

Features

  • Upto 32Klm light output

  • Typical 140lm/W

  • 1-10V dimming interface

Applications

2-lane tunnels: 12-14m width, symmetrical or staggered installation, with up to 60-100km/hr speed, 2- to 3-lane tunnels: 14-15m width, symmetrical installation, with up to 60-100km/hr speed, 2-lane tunnels: 9-10m width, staggered installation, with up to 60-100km/hr speed

See what’s trending: Explore popular products in these families

Specifications

  • Material
    Housing: die-cast aluminiumOptic cover: polycarbonate
  • Light Source
    3030 LED
  • Installation
    Bracket, tilting angle +/- 60D
  • Luminous flux
    up to 32000lm
  • Correlated color temperature - CCT
    4000K3000K
  • Luminaire efficacy
    4000K: 140lm/W
  • Color Rendering index - CRI
    70
  • Power
    up to 240W
  • Mains Voltage
    220-240V, 50/60Hz
  • Control system input
    1-10V
  • Dimming
    1-10VStep dimming
  • Operating Temperature range
    -40 to +55C Ta
  • Ingress protection
    IP66
  • Certification
    IECEE CB, CE, CQC
