MasterConnect LEDtube IA 1200mm UO 16W840 T8

Specifications Show all

General information

Cap base	G13  [ Medium Bi-Pin Fluorescent]
CE mark	Yes
EU RoHS compliant	Yes
Nominal lifetime (nom.)	60000 h
Switching cycle	200000
	Sphere
Tier	MasterConnect

Light technical

Colour Code	840  [ CCT of 4,000 K]
Technical Beam Angle (Nom)	160 °
Lamp Luminous Flux 25°C EL (Nom)	2500 lm
Colour Designation	Cool White (CW)
Colour Temperature, horizontal (Nom)	4000 K
Lamp Luminous Efficacy EM (Nom)	156 lm/W
Colour consistency	<6
Colour Rendering Index,horiz (Nom)	83
LLMF at end of nominal lifetime (nom.)	70 %

Operating and electrical

Input frequency	50 to 60 Hz
Power (Rated) (Nom)	16 W
Lamp current (max.)	76 mA
Lamp current (min.)	69 mA
Starting time (nom.)	0.5 s
Warm-up time to 60% light (nom.)	0.5 s
Power factor (nom.)	0.9
Voltage (Nom)	220-240 V

Temperature

T-ambient (max.)	45 °C
T-ambient (min.)	-20 °C
T-storage (range)	-40°C to 65°C
T storage (max.)	65 °C
T storage (min.)	-40 °C
T-Case maximum (nom.)	50 °C

Controls and dimming

Dimmable

Wireless Dim

Mechanical and housing

Product length	1200 mm
Bulb shape	Tube, double-ended

Approval and application

Energy Efficiency Class	D
Energy-saving product	Yes
Approval marks	RoHS compliance	TUV	CE marking	KEMA Keur certificate
Energy consumption kWh/1,000 hours	16 kWh
	406200

Product data

Full product code	871869966970600
Order product name	MasterConnect LEDtube IA 1200mm UO 16W840 T8
EAN/UPC – product	8718699669706
Order code	929002210402
SAP numerator – quantity per pack	1
Numerator – packs per outer box	10
SAP material	929002210402
Net Weight (Piece)	0.230 kg
