MASTER LEDtube VLE 1200mm HO 14W865 T8

Specifications Show all

General information

Cap base	G13  [ Medium Bi-Pin Fluorescent]
EU RoHS compliant	Yes
Nominal lifetime (nom.)	50000 h
Switching cycle	200000

Light technical

Colour Code	865  [ CCT of 6,500 K]
Technical Beam Angle (Nom)	240 °
Lamp Luminous Flux 25°C EL (Nom)	2100 lm
Colour Designation	Cool Daylight
Colour Temperature, horizontal (Nom)	6500 K
Lamp Luminous Efficacy EM (Nom)	150.00 lm/W
Colour consistency	<6
Colour Rendering Index,horiz (Nom)	83
LLMF at end of nominal lifetime (nom.)	70 %

Operating and electrical

Input frequency	50 to 60 Hz
Power (Rated) (Nom)	14 W
Lamp current (nom.)	66 mA
Starting time (nom.)	0.5 s
Warm-up time to 60% light (nom.)	0.5 s
Power factor (nom.)	0.9
Voltage (Nom)	220-240 V

Temperature

T-ambient (max.)	45 °C
T-ambient (min.)	-20 °C
T-storage (range)	-40°C to 65°C
T storage (max.)	65 °C
T storage (min.)	-40 °C
T-Case maximum (nom.)	55 °C

Controls and dimming

Dimmable

No

Mechanical and housing

Lamp Finish	Frosted
Bulb material	Glass
Product length	1200 mm
Bulb shape	Tube, double-ended

Approval and application

Energy-saving product	Yes
Approval marks	RoHS compliance	KEMA Keur certificate

Product data

Full product code	871951435078600
Order product name	MASTER LEDtube VLE 1200mm HO 14W865 T8
EAN/UPC – product	8719514350786
Order code	929003070308
SAP numerator – quantity per pack	1
Numerator – packs per outer box	10
SAP material	929003070308
Net Weight (Piece)	0.215 kg
