BRP110 LED50/757

Specifications Show all

General information

Driver included	Yes
Optical cover/lens type	Polycarbonate
Control interface	IR remote
Warranty period	2 years
Material	Aluminum

Operating and electrical

Battery type	Lithium Ferro Phosphate
Battery ampere hour	24 Ah
Battery voltage	12.8 V
Battery charging & discharging cycles	2000
Panel type	Mono crystalline
Panel voltage	18 V
Panel peak wattage	50 W
Charge controller type	MPPT
Charge controller wattage	35 W

Controls and dimming

Dimmable	Yes
Configurability	Configurable

Mechanical and housing

Overall length	935 mm
Overall width	380 mm
Overall height	95 mm

Approval and application

Ingress protection code	IP65  [ Dust penetration-protected, jet-proof]
Mech. impact protection code	IK08  [ 5 J vandal-protected]

Initial performance (IEC compliant)

Initial luminous flux (system flux)	5000 lm
Lamp colour temperature	5700 K
Colour Rendering Index	>70

Application conditions

Ambient temperature range	-20 to +50 °C
Ambient temperature range for charging	0 °C to +45 °C
Ambient temperature range for discharging (when light is on)	-20 °C to +50 °C
Autonomy	up to 24 h
Solar dimming profile	First 2 Hrs - On motion : 100%, without motion :30% ; Next 3 Hrs - On motion : 60%, without motion :20% ; Next 6 Hrs On motion : 30%, without motion :10% ; Rest of the Night: On motion : 50%, without motion :30%
Grid connection type	Off grid
Battery location	Inside Luminaire

Product data

Full product code	871951450821700
Order product name	BRP110 LED50/757
EAN/UPC – product	8719514508217
Order code	911401863681
SAP numerator – quantity per pack	1
Numerator – packs per outer box	1
SAP material	911401863681
Net Weight (Piece)	12.450 kg
